Reception — Olive Grove Pavilion
A 110′ clearspan, 144 at king's tables — and the generator drawn where it belongs.
Marisol Estate · Olive Grove Pavilion · 150′ × 104′, open air
Why it is laid out this way
- Twelve 12′ king's tables on 24′ × 14′ centres: 12′ side aisles and 8′ 9″ between chair backs.
- The catering tent, hot boxes and dish station sit on a straight run to the service end of the tables.
- Power, cable ramps, restrooms and the accessible route are on their own layer — the half of a tent plan that decides the night.
What the plan measures
Capacity144 seated
SetupKing's tables under clearspan
Seats placed159
Objects placed128
Event space150′ × 104′, open air
Floor area15,600 ft²
Per seat98.1 ft²
Event typeReception · Social
The room it is drawn in
The event space is surveyed once and every diagram of it inherits this. It is why the plan above can be checked at all.
5points in the traced perimeter
13built features, each with a real height
1typed doors, with swings
Open ground — the perimeter is a property line, not a wall. Floor: lawn.
