Poster Session — Grand Foyer
24 poster boards in a 28′ foyer, with a 12′ aisle and 4′ of reading depth behind each.
The Peregrine Hotel & Conference Center · Grand Foyer · 150′ × 28′, 16′ ceiling
Why it is laid out this way
- A reader stands 4′ back from a board, so a run of posters needs eight feet of depth and nothing else — which is why a foyer beats a ballroom for this.
- Boards stop short of all four ballroom door pairs, so the pre-function keeps working as pre-function while the session runs.
- The centre run only occupies the stretch where the curved glass wall leaves 8′ of depth behind it; at the ends it does not, so there are no boards there.
What the plan measures
Capacity24 boards
SetupTwo poster runs, 12′ aisle
Seats placed0
Objects placed28
Event space150′ × 28′, 16′ ceiling
Floor area4,200 ft²
Event typeConference · Education
The room it is drawn in
The event space is surveyed once and every diagram of it inherits this. It is why the plan above can be checked at all.
29points in the traced perimeter
6built features, each with a real height
6typed doors, with swings
Enclosed room. Floor: stone. Walls: glass.
