Hybrid Session — Vellum Studio
39 in the room and a camera line at 22′ that nobody sits in.
The Peregrine Hotel & Conference Center · Vellum Studio · 52′ × 36′, 12′ ceiling
Why it is laid out this way
- The desk is under the house screen so the in-room audience and the stream see the same background — the thing that is obvious in the room and wrong on the recording.
- The audience starts at 28′, behind the camera line, rather than being placed first and lit around afterwards.
- Video village is beside the AV closet in the north-east corner, where the room's own cabling actually lands.
What the plan measures
Capacity39 in the room
SetupBroadcast set + audience
Seats placed42
Objects placed60
Event space52′ × 36′, 12′ ceiling
Floor area1,872 ft²
Per seat44.6 ft²
Event typeConference · Corporate
The room it is drawn in
The event space is surveyed once and every diagram of it inherits this. It is why the plan above can be checked at all.
5points in the traced perimeter
2built features, each with a real height
2typed doors, with swings
Enclosed room. Floor: carpet. Walls: paint.
